A-S301 | |
---|---|
Specifications | |
Minimum RMS Output Power (8 ohms, 20 Hz-20 kHz) | 60 W + 60 W (0.019% THD) |
Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe) | 95 W + 95 W |
High Dynamic Power/Channel (8/6/4/2 ohms) | 100/120/140/150 W |
Damping Factor | 210 |
Frequency Response | 10 Hz-100 kHz +/-1.0 dB |
Total Harmonic Distortion (CD to Sp Out, 20 Hz-20 kHz) | 0.019% (50 W/8 ohms) |
Signal-to-Noise Ratio (CD) | 99dB (input shorted, 200 mV) |
Audio In / Out | 8 / 2 |
Digital Input | Yes (optical / coaxial) |
Subwoofer Out | Yes |
DC out | Yes |
Pure Direct | Yes |
ToP-ART | Yes |
Standby Power Consumption | 0.5W |
Power Management (Auto Power Standby) | Yes |
Dimensions (W x H x D) | 435 x 151 x 387 mm; 17-1/8” x 6” x 15-1/4” |
Weight | 9.0 kg; 19.8 lbs. |
