XR100 / Pièce

ELECTRONIC SPECIFICATIONS

• Impedance Nominal

  8 Ohms

• Power Rating

  75 to 600 Watts

• Frequency Response

  30Hz to 45kHz

• Sound Pressure Level, 2.8V/1m

  87dB

• Crossover

  300Hz, 2kHz, 8kHz

DRIVER SPECIFICATIONS

• Number of Woofers

  4

• Woofer Size

  6"

• Woofer Type

  Cast Frame, LD/HP®, Poly Cone

• Number of Midranges

  10

• Midrange Size

  2"

• Midrange Type

  8 Inverted Titanium Dome Midranges covering 300Hz to 2kHz, and 2 Inverted Titanium Dome Midrange-Tweeters covering 2kHz to 8kHz

• Number of Tweeters

  1

• Tweeter Size

  3/4"

• Tweeter Type

  Titanium Dome

GENERAL SPECIFICATIONS

• System Type

  Ported 4-Way Floor Standing

• Grille

  Black knit cloth, magnetically attached

• Available Finishes

  Red Walnut, Black

WEIGHTS & DIMENSIONS

• Unit Dimensions (W x H x D)

  8" (20.3cm) x 51" (129.5cm) x 18-1/2" (46.9cm) (including cables and connectors)

• Unit Weight

  68.5 lbs (31.1 kg)

• Shipping Weight

  83 lbs (37.6 kg)
